Replacement solar inverters

Description

Ideal for any solar panel installation that has stopped working. Our replacement inverters can easily get your system back up and running again.

We offer a PV panel inverter to match any size installation. Connected to the home household grid 230v system.

These inverters are single or dual MPPT tracking with or without DC switch to match original installations.

Growatt TLX inverters single MPPT (no DC)

• Max AC – 750w capacity | DC capacity >1050w | 2-3 panels @ 250w
• Max AC – 1000w capacity | DC capacity >1400w | 3-5 panels @ 250w
• Max AC – 1500w capacity | DC capacity >2100w | 5-7 panels @ 250w
• Max AC – 2000w capacity | DC capacity >2800w | 8 panels @ 250w
• Max AC – 2500w capacity | DC capacity >3500w | 12-14 panels @ 250w
• Max AC – 3000w capacity | DC capacity >4200w | 14-16 panels @ 250w



Growatt TL-X inverters dual MPPT (no DC)

• Max AC – 2500w capacity | DC capacity >3500w | 12-14 panels @ 250w
• Max AC – 3000w capacity | DC capacity >4200w | 14-16 panels @ 250w
• Max AC – 3600w capacity | DC capacity >5040w | 16-20 panels @ 250w
• Max AC – 4200w capacity | DC capacity >5880w | 20-22 panels @ 250w
• Max AC – 4600w capacity | DC capacity >6440w | 22-24 panels @ 250w
• Max AC – 5000w capacity | DC capacity >7000w |24-28 panels @ 250w
• Max AC – 6000w capacity | DC capacity >8100w | 30-32 panels @ 250w



Growatt TL-XE -DC inverters dual MPPT (complete with DC switch)

• Max AC – 2500w capacity | DC capacity >3500w | 12-14 panels @ 250w
• Max AC – 3000w capacity | DC capacity >4200w | 14-16 panels @ 250w
• Max AC – 3600w capacity | DC capacity >5040w | 16-20 panels @ 250w
• Max AC – 4200w capacity | DC capacity >5880w | 20-22 panels @ 250w
• Max AC – 4600w capacity | DC capacity >6440w | 22-24 panels @ 250w
• Max AC – 5000w capacity | DC capacity >7000w |24-28 panels @ 250w
• Max AC – 6000w capacity | DC capacity >8100w | 30-32 panels @ 250w

We offer a complete range of replacement solar inverters to match existing PV installations, where the original inverter has stopped working.

GROWATT HYBRID INVERTERS

Also the very latest Growatt Hybrid inverters Dual MPPT (single phase) are available c/w battery backup pack..

• Growatt SPH3000 – 3kw single phase unit (2 MPPT inputs) Can be connected to 3.3kwh or 6.5kwh Growatt batteries
• Growatt SPH3600TL BL-UP – 3.6kw single phase unit (2 MPPT inputs) Can be connected to low voltage batteries
• Growatt SPH5000 – 5kw single phase unit (2 MPPT inputs) Can be connected to 3.3kwh or 6.5kwh Growatt batteries
• Growatt SPH6000 – 6kw single phase unit (2 MPPT inputs) Can be connected to 3.3kwh or 6.5kwh Growatt batteries
• Growatt SPA3000 AC charger. Convert existing solar panel systems into battery storage.
